電氣成套設備就是把一系列的電氣元件，按照一定的規范組合在一起而形成的有機整體的電氣設備。從大的方面來說，它們分為：成套開關設備、箱式變電站、電纜分支箱、變壓器等。
A complete set of electrical equipment is an organic electrical equipment formed by combining a series of electrical components according to certain specifications. Generally speaking, they are divided into complete sets of switchgear, box type substation, cable branch box, transformer, etc.
1、成套開關設備。
1. Complete switchgear.
這里又分為高壓成套開關設備，即高壓開關柜、低壓成套開關設備，即低壓開關柜。
It is also divided into high-voltage switchgear, i.e. high-voltage switchgear and low-voltage switchgear, i.e. low-voltage switchgear.
高壓開關柜的主要類型、型號有：KYN28A-12、GMXt6全絕緣環網柜、GMX375-550小型化開關柜、GMX65-12固體絕緣環網柜、HXGN15-12開關柜等。
The main types and models of high-voltage switchgear include kyn28a-12, gmxt6 fully insulated ring network cabinet, gmx375-550 miniaturized switchgear, gmx65-12 solid insulated ring network cabinet, hxgn15-12 switchgear, etc.
低壓開關柜的型號主要有：ZMCS、MNS、GCK抽出式低壓開關柜、GGD交流低壓配電柜、ZMXL低壓動力配電柜等。
The models of low-voltage switchgear mainly include: zmcs, MNS, GCK withdrawable low-voltage switchgear, GGD AC low-voltage distribution cabinet, zmxl low-voltage power distribution cabinet, etc.
2、箱式變電站。
2. Box type substation.
箱式變電站是當今主要的流行的變電站形式之一，以可移動、預制化、體積小等特點，在眾多的變電場所得到應用。
Box type substation is one of the main popular forms of substation. It has been applied in many substation places with the characteristics of mobility, prefabrication and small volume.
箱式變電站的類型有：歐式箱變、美式箱變、小型化箱變、地埋式箱變、預制艙變電站等。其實小型化箱變、預制艙等是新一代、更加智能化的箱式變電站。
The types of box type substation include: European box type substation, American box type substation, miniaturized box type substation, buried box type substation, prefabricated compartment substation, etc. In fact, miniaturized box transformer and prefabricated cabin are a new generation and more intelligent box transformer substation.
3、電纜分支箱。
3. Cable branch box.
電纜分支箱類型有：DFW-12歐式電纜分接箱；DFW低壓電纜分支箱；XGW-12~24kV環網箱（開閉所）。
Type of cable branch box: dfw-12 European cable branch box; DFW low voltage cable branch box; Xgw-12 ~ 24kV ring cage (switching post).
4、配電變壓器。
4. Distribution transformer.
變壓器是我們生活生產中，變壓配電的重要的設備之一。從絕緣方式上分為干式、油浸式變壓器。油浸式變電站型號為S11、S13，干式變壓器為SCB10、SCB11、SCB12、SCB13.干式變壓器一般用于戶內、油浸式一般用于戶外。
Transformer is one of the most important equipment for voltage transformation and distribution in our life and production. In terms of insulation mode, it is divided into dry-type and oil immersed transformers. The models of oil immersed substations are S11 and S13, and the dry-type transformers are scb10, scb11, scb12 and scb13. The dry-type transformers are generally used indoors and the oil immersed transformers are generally used outdoors.
電氣成套設備的供應。
Supply of complete electrical equipment.
因每個項目的配電的參數各不一樣，所以每個電氣設備的都對應一個配電項目。而成套電氣設備的供應基本上都是按照客戶的需要而個性化定制的。由客戶咨詢進而發來電氣圖紙，廠家根據其進行報價、制造、安裝出廠。
Because the distribution parameters of each project are different, each electrical equipment corresponds to a distribution project. The supply of complete sets of electrical equipment is basically customized according to the needs of customers. The customer consults and then sends the electrical drawings, and the manufacturer quotes, manufactures, installs and leaves the factory according to them.
